PCD Flooring Joint Profile Cutter Set
This PCD set is illustrated with two cutter heads and a wooden flooring-joint cross-section. It is intended for profile machining matched to the required flooring section.
Pictured Specifications
| Outside diameter (mm) | Bore (mm) | Workpiece thickness (mm) | Groove depth (mm) | Teeth |
|---|---|---|---|---|
| 120 | 40 | 22 | 4 | 6 |
Other Listed Sizes
| Outside diameter (mm) | Workpiece thickness (mm) | Teeth |
|---|---|---|
| 100 | 15 | 6 |
| 100 | 18 | 6 |
Workpiece and Machine Selection
Listed applications include MDF/density board, silicate board and hard solid-wood materials, with CNC spindle milling machines, four-side moulders, wood moulding machines and tenoning machines. Supply the exact flooring joint drawing, material and spindle details to confirm suitability.
Request a Quote
Send your material, machine model, required dimensions, rotation and quantity to info@lihotools.com. A profile drawing or current-tool photograph helps us confirm the configuration.
Confirm the specification for your application
Send the joint drawing and board construction. The pictured D120, 40 mm-bore, 22 mm-working-thickness, 4 mm-groove version differs from the D100 options; confirm the complete set arrangement.
Request a product quotation
Include a current-tool photo or dimensioned drawing where available so Liho Tools can check the required configuration and machine fit.
Explore PCD Flooring Cutters or send your application details to Liho Tools.
