PCD Fine Trimming Cutter for Edge Banding Machines
This PCD fine trimming cutter is designed for finishing edge-banded panels after rough trimming. It produces the final profile on compatible edge banding machines for cabinet, door and panel-furniture production.
Applications
- Fine trimming after edge application
- Final profiling of edge-banded panels
- Panel furniture, cabinet and door production
Available Specification
| Diameter D mm | Cutting Height H mm | Bore d mm | Teeth Z | Radius R mm |
|---|---|---|---|---|
| 75 | 16 | 20 / 22 | 4 / 6 | 1.5 / 2 / 3 |
Machine interface, rotation direction and final profile must be confirmed before ordering. Please provide the machine model, edge-band material and required radius for selection.
